US Stock ZAC Broken Tap Remover 800W Tap Disintegrator Portable Edm Machine 110V Tap Burner Tap Eroder for M2-M20 (5/64'' to 25/32'') Broken Taps Drill Bits Bolts Removing without Damage
4.3 (132 items)
Limited Time SaleUS$959.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210028166 | Release Date | 2026/04/02 | List Price | US$639.60 | Model Number | 210028166 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- INTRODUCTION: ZAC broken tap remover, can fast remove M2 to M20 (5/64'' to 25/32'') broken taps broken bolts drill bits without damage threads and workpiece. Input Voltage: 110V. Output Power: 800W; Electrode Chuck Diameter: 0.8-10mm; Max Process Depth of Spindle Servo: 70mm; Work Liquid: Tap Water; Short Hole Processing Speed: ≈1mm/min Electrode Φ4(Processing Material: Hardened Steel). Max Process Depth 70mm/2.78in.Machine Dimension:15*6.3*11.8in. Net Weight: 35.3lbs
- HIGHER PERFORMANCE: Different from traditional broken tap extractor tools and kits, this kind of tap disintegrator edm machine can save much and and labor energy that the depth can be set so that the broken taps can be removed without person around, and knob can be returned when removing is over.
- EASY TO OPERATE: Also different from the traditional broken bolts extractors tools and tools, you only need to turn on switches and adjust current and then the broken taps can be easily removed from the workpiece. Besides, with the small volume and lightweight design so that the removing efficiency can be highly improved without space limitations.
- HIGHER EFFICIENCY: With seperated workhead, the processing direction can be 360°adjusted to fit the workpiece. Adopts magnetic base and cross connector to support the workhead which provides you more stable working process. Suitable for various workpieces and machine shop, heavy equipment repair, aircraft, auto/truck repair, etc.
- CARING WARRANTY: We provide 1 year guarantee for the whole machine.During the warranty, we would offer free repair only when the damages are caused by technical deficiencies of the product itself, not man made errors, namely, the damages were done by mishandling the machine, including the new parts that needed for the repair.
| Size | EDM-8C |
|---|---|
| Color | 800w |
| Voltage | 110 Volts |
| Wattage | 800 watts |
| Item Weight | 35.2 pounds |
| Part Number | ZACM031801ALN |
| Manufacturer | Luoyang ZAC Industrial |
| Power Source | ac |
| Item model number | EDM-8C |
| Batteries Included | No |
| Batteries Required | No |
| Product Dimensions | 14.96 x 6.3 x 11.81 inches |
| Included Components | ø1*100mm × 2 pcs ø1.5*100mm × 2 pcs ø2*100mm × 2 pcs ø3*100mm × 2 pcs ø4*100mm × 1 pcs ø5*100mm × 1 pcs Power line*1 Working head*1 Spinner*1 Electrode chuck*1 Water pump*1 Servo cable*1 Cross connector*1 Instruction manual*1 Universal faucet*1 Magnetic base*1 Alligator clips*1 |
